2004 -2019 Yamaha YFZ450/R 12.75:1 95mm std bore piston kit

• Bore:  95mm
• Comp Ratio:  12.5:1 439cc; 12.75:1 449cc
• Piston #:  M1000
• CPK #:  CPK1000
• Rod #:  04-05 9660; 06-08 custom 09-15 8808
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3740
• Gasket Only #:  YFZ450 C3066; YFZ450R C7908

2004-2019 Yamaha YFZ450/R 13.25:1 95mm std bore piston kit

• Bore:  95mm
• Comp Ratio:  13.0:1 439cc; 13.25:1 449cc
• Piston #:  M1001
• CPK #:  CPK1001
• Rod #:  04-05 9660 06-08 custom; 09-15 8808
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3740
• Gasket Only #:  YFZ450 C3066; YFZ450R C7908

2004-2019 Yamaha YFZ 450/R 13.75:1 95mm standard bore piston kit

• Bore:  95mm
• Comp Ratio:  13.25:1 439cc; 13.5:1 449cc
• Piston #:  M1002
• CPK #:  CPK1002
• Rod #:  04-05 9660 06-08 custom; 09-15 8808
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3740
• Gasket Only #:  YFZ450 C3066; YFZ450R C7908

2004- 2019 Yamaha YFZ450/R 12.75:1 97mm +2mm oversize bore piston kit

• Bore:  97mm
• Comp Ratio:  12.5:1 458cc; 12.75:1 468cc
• Piston #:  M1006
• CPK #:  CPK1006
• Rod #:  04-05 9660 06-08 custom; 09-15 8808
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3819
• Gasket Only #:  YFZ450 C3068; YFZ450R C3178

2004-2019 Yamaha YFZ450/R 13.25:1 97mm +2mm oversize bore piston kit

• Bore:  97mm
• Comp Ratio:  13.0:1 458cc; 13.25:1 468cc
• Piston #:  M1007
• CPK #:  CPK1007
• Rod #:  04-05 9660 06-08 custom; 09-15 8808
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3819
• Gasket Only #:  YFZ450 C3068; YFZ450R C3178

2004-2019 Yamaha YFZ450/R 13.75:1 97mm +2mm oversize bore Piston Kit

• Bore:  97mm
• Comp Ratio:  13.5:1 458cc; 13.75:1 468cc
• Piston #:  M1008
• CPK #:  CPK1008
• Rod #:  04-05 9660 06-08 custom; 09-15 8808
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3819
• Gasket Only #:  YFZ450 C3068; YFZ450R C3178

2004-2019 Yamaha YFZ450/R 12.75:1, 98mm +3mm oversize piston kit

• Bore:  98mm
• Comp Ratio:  12.5:1 468cc; 12.75:1 478cc
• Piston #:  M1009
• CPK #:  CPK1009
• Rod #:  04-05 9660 06-08 custom; 09-15 8808
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3858
• Gasket Only #:  YFZ450 C3068; YFZ450R C3178

2004-2019 Yamaha YFZ 450 13.75:1 98mm +3mm oversize bore piston kit

• Bore:  98mm
• Comp Ratio:  13.5:1 468cc; 13.75:1 478cc
• Piston #:  M1085
• CPK #:  CPK1085
• Rod #:  04-05 9660 06-08 custom; 09-15 8808
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3858
• Gasket Only #:  YFZ450 C3068; YFZ450R C3178

2004 -2019 Yamaha YFZ450/R 11.8:1 :1 95mm std bore piston kit

• Bore:  95mm
• Comp Ratio:  11.8:1 439cc; 12.1:1 449cc
• Piston #:  M1100
• CPK #:  CPK1100
• Rod #:  04-05 9660; 06-08 custom 09-15 8808
• Pin #:  787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3740
• Gasket Only #:  YFZ450 C3066; YFZ450R C7908

2004-2019 Yamaha YFZ450/R Race 13.5:1 95mm std bore piston kit

• Bore:  95mm
• Comp Ratio:  13.25:1 439cc; 13.5:1 449cc
• Piston #:  MX1026
• CPK #:  YFZ450 CPKX1026; YFZ450R CPKX1126
• Rod #:  04-05 9660 06-08 custom; 09-15 8808
• Pin #:  S787-2000-15C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3740
• Gasket Only #:  YFZ450 C3066; YFZ450R C7908

2004-2019 Yamaha YFZ 450 13.5:1 95mm std bore profiled pin bore pro race piston kit

• Bore:  95mm
• Comp Ratio:  13.25:1 439cc; 13.5:1 449cc
• Piston #:  MX1026-P
• CPK #:  YFZ450 CPKX1026-P; YFZ450R CPKX1126-P
• Rod #:  04-05 9660 06-08 custom; 09-15 8808
• Pin #:  S787-2000-15C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3740
• Gasket Only #:  YFZ450 C3066; YFZ450R C7908

2004-2019 Yamaha YFZ450 13.5:1 95mm std bore platinum series 1mm smaller pin/ 3.5mm long rod piston kit

• Bore:  95mm
• Comp Ratio:  13.25:1 439cc; 13.5:1 449cc
• Piston #:  MX1P26
• CPK #:  YFZ450 CPKX1P26; YFZ450R CPKX1P26R
• Rod #:  04-05 6130; 06-07 6129 09-18 8802
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3740
• Gasket Only #:  YFZ450 C3066; YFZ450R C7908

2004-2019 Yamaha YFZ450 13.5:1 95mm std bore platinum series 1mm smaller pin/ 3.5mm long rod, profiled pin bore pro race piston kit

• Bore:  95mm
• Comp Ratio:  13.25:1 439cc; 13.5:1 449cc
• Piston #:  MX1P26-P
• CPK #:  YFZ450 CPKX1P26-P; YFZ450R CPKX1P26R-P
• Rod #:  04-05 6130; 06-07 6129 09-18 8802
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CP9500C
• Gasket Only #:  YFZ450 C3066; YFZ450R C7908

2004 -2019 Yamaha YFZ450/R 12.75:1 95mm std bore piston kit

• Bore:  95mm
• Comp Ratio:  12.5:1 439cc; 12.75:1 449cc
• Piston #:  M1000
• CPK #:  CPK1000
• Rod #:  04-05 9660; 06-08 custom 09-15 8808
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3740
• Gasket Only #:  YFZ450 C3066; YFZ450R C7908

2004-2019 Yamaha YFZ450/R 13.25:1 95mm std bore piston kit

• Bore:  95mm
• Comp Ratio:  13.0:1 439cc; 13.25:1 449cc
• Piston #:  M1001
• CPK #:  CPK1001
• Rod #:  04-05 9660 06-08 custom; 09-15 8808
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3740
• Gasket Only #:  YFZ450 C3066; YFZ450R C7908

2004-2019 Yamaha YFZ 450/R 13.75:1 95mm standard bore piston kit

• Bore:  95mm
• Comp Ratio:  13.25:1 439cc; 13.5:1 449cc
• Piston #:  M1002
• CPK #:  CPK1002
• Rod #:  04-05 9660 06-08 custom; 09-15 8808
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3740
• Gasket Only #:  YFZ450 C3066; YFZ450R C7908

2004- 2019 Yamaha YFZ450/R 12.75:1 97mm +2mm oversize bore piston kit

• Bore:  97mm
• Comp Ratio:  12.5:1 458cc; 12.75:1 468cc
• Piston #:  M1006
• CPK #:  CPK1006
• Rod #:  04-05 9660 06-08 custom; 09-15 8808
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3819
• Gasket Only #:  YFZ450 C3068; YFZ450R C3178

2004-2019 Yamaha YFZ450/R 13.25:1 97mm +2mm oversize bore piston kit

• Bore:  97mm
• Comp Ratio:  13.0:1 458cc; 13.25:1 468cc
• Piston #:  M1007
• CPK #:  CPK1007
• Rod #:  04-05 9660 06-08 custom; 09-15 8808
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3819
• Gasket Only #:  YFZ450 C3068; YFZ450R C3178

2004-2019 Yamaha YFZ450/R 13.75:1 97mm +2mm oversize bore Piston Kit

• Bore:  97mm
• Comp Ratio:  13.5:1 458cc; 13.75:1 468cc
• Piston #:  M1008
• CPK #:  CPK1008
• Rod #:  04-05 9660 06-08 custom; 09-15 8808
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3819
• Gasket Only #:  YFZ450 C3068; YFZ450R C3178

2004-2019 Yamaha YFZ450/R 12.75:1, 98mm +3mm oversize piston kit

• Bore:  98mm
• Comp Ratio:  12.5:1 468cc; 12.75:1 478cc
• Piston #:  M1009
• CPK #:  CPK1009
• Rod #:  04-05 9660 06-08 custom; 09-15 8808
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3858
• Gasket Only #:  YFZ450 C3068; YFZ450R C3178

2004-2019 Yamaha YFZ 450 13.75:1 98mm +3mm oversize bore piston kit

• Bore:  98mm
• Comp Ratio:  13.5:1 468cc; 13.75:1 478cc
• Piston #:  M1085
• CPK #:  CPK1085
• Rod #:  04-05 9660 06-08 custom; 09-15 8808
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3858
• Gasket Only #:  YFZ450 C3068; YFZ450R C3178

2004 -2019 Yamaha YFZ450/R 11.8:1 :1 95mm std bore piston kit

• Bore:  95mm
• Comp Ratio:  11.8:1 439cc; 12.1:1 449cc
• Piston #:  M1100
• CPK #:  CPK1100
• Rod #:  04-05 9660; 06-08 custom 09-15 8808
• Pin #:  787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3740
• Gasket Only #:  YFZ450 C3066; YFZ450R C7908

2004-2019 Yamaha YFZ450/R Race 13.5:1 95mm std bore piston kit

• Bore:  95mm
• Comp Ratio:  13.25:1 439cc; 13.5:1 449cc
• Piston #:  MX1026
• CPK #:  YFZ450 CPKX1026; YFZ450R CPKX1126
• Rod #:  04-05 9660 06-08 custom; 09-15 8808
• Pin #:  S787-2000-15C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3740
• Gasket Only #:  YFZ450 C3066; YFZ450R C7908

2004-2019 Yamaha YFZ 450 13.5:1 95mm std bore profiled pin bore pro race piston kit

• Bore:  95mm
• Comp Ratio:  13.25:1 439cc; 13.5:1 449cc
• Piston #:  MX1026-P
• CPK #:  YFZ450 CPKX1026-P; YFZ450R CPKX1126-P
• Rod #:  04-05 9660 06-08 custom; 09-15 8808
• Pin #:  S787-2000-15C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3740
• Gasket Only #:  YFZ450 C3066; YFZ450R C7908

2004-2019 Yamaha YFZ450 13.5:1 95mm std bore platinum series 1mm smaller pin/ 3.5mm long rod piston kit

• Bore:  95mm
• Comp Ratio:  13.25:1 439cc; 13.5:1 449cc
• Piston #:  MX1P26
• CPK #:  YFZ450 CPKX1P26; YFZ450R CPKX1P26R
• Rod #:  04-05 6130; 06-07 6129 09-18 8802
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3740
• Gasket Only #:  YFZ450 C3066; YFZ450R C7908

2004-2019 Yamaha YFZ450 13.5:1 95mm std bore platinum series 1mm smaller pin/ 3.5mm long rod, profiled pin bore pro race piston kit

• Bore:  95mm
• Comp Ratio:  13.25:1 439cc; 13.5:1 449cc
• Piston #:  MX1P26-P
• CPK #:  YFZ450 CPKX1P26-P; YFZ450R CPKX1P26R-P
• Rod #:  04-05 6130; 06-07 6129 09-18 8802
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CP9500C
• Gasket Only #:  YFZ450 C3066; YFZ450R C7908

2005-2007 Suzuki KingQuad 700 11.5:1 102mm std bore x 85mm stroke (695cc) piston kit

• Bore:  102mm
• Comp Ratio:  11.5:1
• Piston #:  M4013A
• CPK #:  CPK4013A
• Rod #:  N/A
• Pin #:  W905-2250-15CP1C
• Locks #:  905X073 SWL
• Rings #:  CPN-4016
• Gasket Only #:  C3128

2005-2007 Suzuki King Quad 700 11.5:1 106mm +4mm oversize bore x 85mm stroke piston kit

• Bore:  106mm
• Comp Ratio:  11.5:1
• Piston #:  M4014
• CPK #:  CPK4014
• Rod #:  N/A
• Pin #:  W905-2250-15CP1C
• Locks #:  905X073 SWL
• Rings #:  1-S10-4170-5 2-S20-4170-5 3-H30-4170-0NC
• Gasket Only #:  C3128

2005-2007 Suzuki King Quad 700 12.5:1 106mm +4mm oversize bore x 85mm stroke piston kit

• Bore:  106mm
• Comp Ratio:  12.5:1
• Piston #:  M4022
• CPK #:  CPK4022
• Rod #:  N/A
• Pin #:  W905-2250-15CP1C
• Locks #:  905X073 SWL
• Rings #:  RS1000NCR-4170-0
• Gasket Only #:  C3128

2005-2007 Suzuki King Quad 700 11.5:1 104mm +2mm oversize bore x 85mm stroke piston kit

• Bore:  104mm
• Comp Ratio:  11.5:1
• Piston #:  M4051
• CPK #:  CPK4051
• Rod #:  N/A
• Pin #:  W905-2250-15CP1C
• Locks #:  905X073 SWL
• Rings #:  RS1318-4090-5THG
• Gasket Only #:  C3128

2005-2007 Suzuki RM-Z 12.5:1 98mm +2.5mm oversize bore x 62.8mm stroke (473cc) piston kit

• Bore:  98mm
• Comp Ratio:  12.5:1
• Piston #:  M3005
• CPK #:  CPK3005
• Rod #:  8809
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPNZ-3858
• Gasket Only #:  C3127

2005-2007 Suzuki RM-Z450 13.0:1 95.5mm std bore x 62.8mm stroke (449cc) piston kit

• Bore:  95.5mm
• Comp Ratio:  13.0:1
• Piston #:  M3006A
• CPK #:  CPK3006A
• Rod #:  8809
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3759
• Gasket Only #:  C3102

2005-2007 Suzuki RM-Z450 13.5:1 95.5mm std bore x 62.8mm stroke (449cc) piston kit

• Bore:  95.5mm
• Comp Ratio:  13.5:1
• Piston #:  M4009A
• CPK #:  CPK4009A
• Rod #:  8809
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3759
• Gasket Only #:  C3102

2005-2007 Suzuki RM-Z450 13.5:1 95.5mm std bore x 62.8mm stroke (449cc) piston kit

• Bore:  95.5mm
• Comp Ratio:  13.5:1
• Piston #:  MX4009A
• CPK #:  CPKX4009A
• Rod #:  8809
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3759
• Gasket Only #:  C3102

2005-2008 Suzuki GSXR 1000 13.5:1 75mm +1.6mm oversize bore x 59mm stroke (1043cc) piston kit

• Bore:  75mm
• Comp Ratio:  13.5:1
• Piston #:  M4018-050
• CPK #:  CPK4018
• Rod #:  4722
• Pin #:  591-1810-11CP3C
• Locks #:  591x050 SWL
• Rings #:  CPUG-2953
• Gasket Only #:  Call

2005-2008 Suzuki GSXR 1000 10.0:1 73.4mm std bore x 59mm stroke piston kit

• Bore:  73.4mm
• Comp Ratio:  13.5:1
• Piston #:  M4047
• CPK #:  CPK4047
• Rod #:  4722
• Pin #:  591-1500-13CP1C
• Locks #:  591x050 SWL
• Rings #:  MAC07340
• Gasket Only #:  Call

2005-2008 Suzuki GSXR 1000 12.0:1 73.4mm std bore x 59mm stroke nitrous 80 shot piston kit

• Bore:  73.4mm
• Comp Ratio:  12.0:1
• Piston #:  M4056 ***
• CPK #:  Call
• Rod #:  4722
• Pin #:  591-2000-14CP1C
• Locks #:  591x050 SWL
• Rings #:  MAC07341
• Gasket Only #:  Call

2005-2008 Suzuki GSXR 1000 13.5:1 73.4mm std bore x 59mm stroke piston kit for turbo use 15psi 550 hp

• Bore:  73.4mm
• Comp Ratio:  10.0:1
• Piston #:  M4058 **
• CPK #:  Call
• Rod #:  4722
• Pin #:  591-2000-14CP1C
• Locks #:  591x050 SWL
• Rings #:  MAC07340
• Gasket Only #:  Call

2005-2008 Suzuki GSXR 1000 13.5:1 76mm +2.6mm oversize bore x 59mm stroke (1078cc) piston kit

• Bore:  76mm
• Comp Ratio:  13.5:1
• Piston #:  MX4019C-050
• CPK #:  CPKX4019C
• Rod #:  4722
• Pin #:  591-1650-13CP1C
• Locks #:  591x050 SWL
• Rings #:  CPXG-7600C
• Gasket Only #:  C8602-27

2005-2008 Suzuki GSXR 1000 12.5:1 76mm +2.6mm oversize bore +4mm stroke std pin location (1142cc) piston kit

• Bore:  76mm
• Comp Ratio:  12.5:1
• Piston #:  MX4041C-050 *
• CPK #:  CPKX4041C-050
• Rod #:  4722
• Pin #:  591-1650-13CP1C
• Locks #:  591x050 SWL
• Rings #:  CP7600C
• Gasket Only #:  C8602-28

2005-2013 YZ250F 13.5:1 77mm std bore x 53.6mm stroke (250cc), piston kit

• Bore:  77mm
• Comp Ratio:  13.5:1
• Piston #:  M1034C
• CPK #:  CPK1034C
• Rod #:  8807
• Pin #:  W630-1650-13CP1C
• Locks #:  630x050 SWL
• Rings #:  CP7700C
• Gasket Only #:  C3057

2005-2013 YZ250F 13.5:1 77mm std bore x 53.6mm stroke (250cc), piston kit

• Bore:  77mm
• Comp Ratio:  13.5:1
• Piston #:  MX1034C
• CPK #:  CPKX1034C
• Rod #:  8807
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7700C
• Gasket Only #:  C3057

2005-2013 YZ250F 14.0:1 77mm +2mm bore x 53.6mm stroke (250cc) piston kit

• Bore:  77mm
• Comp Ratio:  14.0:1
• Piston #:  MX1035C
• CPK #:  CPKX1035C
• Rod #:  8807
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7700C
• Gasket Only #:  C3057

2005-2013 YZ250F 12.5:1 79mm +2mm bore x 53.6mm stroke (263cc) piston kit

• Bore:  79mm
• Comp Ratio:  12.5:1
• Piston #:  MX1036C
• CPK #:  CPKX1036C
• Rod #:  8807
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7900C
• Gasket Only #:  C3057

2005-2013 YZ250F 13.5:1 80mm +3mm bore x 53.6mm stroke (269cc) piston kit

• Bore:  80mm
• Comp Ratio:  13.5:1
• Piston #:  MX1050C
• CPK #:  CPKX1050C
• Rod #:  8807
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP8000C
• Gasket Only #:  C3059

2005-2013 YZ250F 14.25:1 77mm std bore x 53.6mm stroke (250cc) piston kit

• Bore:  77mm
• Comp Ratio:  14.25:1
• Piston #:  MX1135C
• CPK #:  CPKX1135C
• Rod #:  8807
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7700C
• Gasket Only #:  C3057

2005-2013 Yamaha YZ250F 14.0:1 77mm std bore x 53.6mm stroke platinum series 1mm smaller pin/ 2mm longer rod (250cc) piston kit

• Bore:  77mm
• Comp Ratio:  14.0:1
• Piston #:  MX1P35C
• CPK #:  CPKX1P35C
• Rod #:  6126
• Pin #:  S591-1650-13C
• Locks #:  591x040 SWL
• Rings #:  CP7700C
• Gasket Only #:  C3057

2005-2015 RXP 215/255/260 8.4:1 turbo 100mm std bore x 63.4mm stroke (1494cc) piston kit

• Bore:  100mm
• Comp Ratio:  8.4:1
• Piston #:  M9032A
• CPK #:  CPK9032A
• Rod #:  5476
• Pin #:  905-2250-19CP3C
• Locks #:  905X073 SWL
• Rings #:  CPN-3937
• Gasket Only #:  H30220305

2005-2015 RXP 215/255/260 8.4:1 turbo 100.25mm +.25mm oversize bore x 63.4mm stroke (1501cc) piston kit

• Bore:  100.25mm
• Comp Ratio:  8.4:1
• Piston #:  M9033
• CPK #:  CPK9033
• Rod #:  5476
• Pin #:  905-2250-19CP3C
• Locks #:  905X073 SWL
• Rings #:  SWF-20064-3
• Gasket Only #:  H30220305

2005-2015 RXP 215/255/260 9.5:1 turbo 100mm std bore x 63.4mm stroke (1494cc) piston kit

• Bore:  100mm
• Comp Ratio:  9.5:1
• Piston #:  M9039A
• CPK #:  CPK9039A
• Rod #:  5476
• Pin #:  905-2250-19CP3C
• Locks #:  905X073 SWL
• Rings #:  CPN-3937
• Gasket Only #:  H30220305

2005-2015 RXP 215/255/260 9.5:1 turbo 100.25mm +.25mm oversize bore x 63.4mm stroke (1501cc) piston kit

• Bore:  100.25mm
• Comp Ratio:  9.5:1
• Piston #:  M9040
• CPK #:  CPK9040
• Rod #:  5476
• Pin #:  905-2250-19CP3C
• Locks #:  905X073 SWL
• Rings #:  SWF-20064-3
• Gasket Only #:  H30220305

2005-2015 RXP 215/255/260 8.2:1 turbo 100.5mm +.5mm oversize bore x 63.4mm stroke (1508cc) piston kit

• Bore:  100.5mm
• Comp Ratio:  8.2:1
• Piston #:  M9041
• CPK #:  CPK9041
• Rod #:  5476
• Pin #:  905-2250-19CP3C
• Locks #:  905X073 SWL
• Rings #:  CPN-3957
• Gasket Only #:  H30220305

2005-2015 RXP 215/255/260 9.5:1 turbo, 100.5mm +.5mm oversize bore x 63.4mm stroke (1508cc) piston kit

• Bore:  100.5mm
• Comp Ratio:  9.5:1
• Piston #:  M9042
• CPK #:  CPK9042
• Rod #:  5476
• Pin #:  905-2250-19CP3C
• Locks #:  905X073 SWL
• Rings #:  CPN-3957
• Gasket Only #:  H30220305

2005-2015 RXP 215/255/260 8.4:1 turbo 100mm std bore x 63.4mm stroke (1494cc) piston kit

• Bore:  100mm
• Comp Ratio:  8.4:1
• Piston #:  M9032A
• CPK #:  CPK9032A
• Rod #:  5476
• Pin #:  905-2250-19CP3C
• Locks #:  905X073 SWL
• Rings #:  CPN-3937
• Gasket Only #:  H30220305

2005-2015 RXP 215/255/260 8.4:1 turbo 100.25mm +.25mm oversize bore x 63.4mm stroke (1501cc) piston kit

• Bore:  100.25mm
• Comp Ratio:  8.4:1
• Piston #:  M9033
• CPK #:  CPK9033
• Rod #:  5476
• Pin #:  905-2250-19CP3C
• Locks #:  905X073 SWL
• Rings #:  SWF-20064-3
• Gasket Only #:  H30220305

2005-2015 RXP 215/255/260 9.5:1 turbo 100mm std bore x 63.4mm stroke (1494cc) piston kit

• Bore:  100mm
• Comp Ratio:  9.5:1
• Piston #:  M9039A
• CPK #:  CPK9039A
• Rod #:  5476
• Pin #:  905-2250-19CP3C
• Locks #:  905X073 SWL
• Rings #:  CPN-3937
• Gasket Only #:  H30220305

2005-2015 RXP 215/255/260 9.5:1 turbo 100.25mm +.25mm oversize bore x 63.4mm stroke (1501cc) piston kit

• Bore:  100.25mm
• Comp Ratio:  9.5:1
• Piston #:  M9040
• CPK #:  CPK9040
• Rod #:  5476
• Pin #:  905-2250-19CP3C
• Locks #:  905X073 SWL
• Rings #:  SWF-20064-3
• Gasket Only #:  H30220305

2005-2015 RXP 215/255/260 8.2:1 turbo 100.5mm +.5mm oversize bore x 63.4mm stroke (1508cc) piston kit

• Bore:  100.5mm
• Comp Ratio:  8.2:1
• Piston #:  M9041
• CPK #:  CPK9041
• Rod #:  5476
• Pin #:  905-2250-19CP3C
• Locks #:  905X073 SWL
• Rings #:  CPN-3957
• Gasket Only #:  H30220305

2005-2015 RXP 215/255/260 9.5:1 turbo, 100.5mm +.5mm oversize bore x 63.4mm stroke (1508cc) piston kit

• Bore:  100.5mm
• Comp Ratio:  9.5:1
• Piston #:  M9042
• CPK #:  CPK9042
• Rod #:  5476
• Pin #:  905-2250-19CP3C
• Locks #:  905X073 SWL
• Rings #:  CPN-3957
• Gasket Only #:  H30220305

2005-2015 RXP 215/255/260 8.4:1 turbo 100mm std bore x 63.4mm stroke (1494cc) piston kit

• Bore:  100mm
• Comp Ratio:  8.4:1
• Piston #:  M9032A
• CPK #:  CPK9032A
• Rod #:  5476
• Pin #:  905-2250-19CP3C
• Locks #:  905X073 SWL
• Rings #:  CPN-3937
• Gasket Only #:  H30220305
