CP Carrillo » 2007

1996-2009 Honda XR400R 10.0:1 85mm std bore x 70mm stroke (397cc) piston kit

• Bore:  85mm
• Comp Ratio:  10.0:1
• Piston #:  M2002
• CPK #:  CPK2002
• Rod #:  N/A
• Pin #:  787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN-3347
• Gasket Only #:  C7825

1996-2009 Honda XR400R 11.0:1 85mm std bore x 70mm stroke (397cc) piston kit

• Bore:  85mm
• Comp Ratio:  11.0:1
• Piston #:  M2003
• CPK #:  CPK2003
• Rod #:  N/A
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN-3347
• Gasket Only #:  C7825

1996-2009 Honda XR400R 12.5:1 87mm +2mm oversize bore x 70mm stroke (415cc) piston kit

• Bore:  87mm
• Comp Ratio:  12.5:1
• Piston #:  M2008
• CPK #:  CPK2008
• Rod #:  N/A
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN-3425
• Gasket Only #:  C7826

1996-2009 Honda XR400R 11.5:1 89mm Bore +4mm oversize bore x 70mm stroke (435cc) piston kit

• Bore:  89mm
• Comp Ratio:  11.5:1
• Piston #:  M2033
• CPK #:  CPK2033
• Rod #:  N/A
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN-3504
• Gasket Only #:  C7826

1996-2016 Honda TRX400EX 10.0:1 85mm std bore x 70mm stroke (397cc) piston kit

• Bore:  85mm
• Comp Ratio:  10.0:1
• Piston #:  M2002
• CPK #:  CPK2002
• Rod #:  5034
• Pin #:  787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN-3347
• Gasket Only #:  C7825

1996-2016 Honda TRX400EX 11.0:1 85mm std bore x 70mm stroke (397cc) piston kit

• Bore:  85mm
• Comp Ratio:  11.0:1
• Piston #:  M2003
• CPK #:  CPK2003
• Rod #:  5034
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN-3347
• Gasket Only #:  C7825

1996-2016 Honda TRX400EX 12.5:1 87mm +2mm oversize bore x 70mm stroke (415cc) piston kit

• Bore:  87mm
• Comp Ratio:  12.5:1
• Piston #:  M2008
• CPK #:  CPK2008
• Rod #:  5034
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN-3425
• Gasket Only #:  C7826

1996-2016 Honda TRX400EX 11.5:1 89mm +4mm oversize bore x 70mm stroke (435cc) piston kit

• Bore:  89mm
• Comp Ratio:  11.5:1
• Piston #:  M2033
• CPK #:  CPK2033
• Rod #:  5034
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN-3504
• Gasket Only #:  C7826

1999-2007 Suzuki Hayabusa 12.5:1 83mm +2mm oversize bore x 63mm stroke (1363cc) piston kit

• Bore:  83mm
• Comp Ratio:  12.5:1
• Piston #:  M4002
• CPK #:  CPK4002
• Rod #:  4720
• Pin #:  787-2000-12CP1C
• Locks #:  787x050 SWL
• Rings #:  CPNG-2-3268
• Gasket Only #:  C8657

1999-2007 Suzuki Hayabusa 14:1 gas ports 83mm +2mm oversize bore x 63mm stroke (1363cc) piston kit

• Bore:  83mm
• Comp Ratio:  14.0:1
• Piston #:  M4003
• CPK #:  CPK4003
• Rod #:  4720
• Pin #:  787-2000-12CP1C
• Locks #:  787x050 SWL
• Rings #:  CPNG-2-3268
• Gasket Only #:  C8657

1999-2007 Suzuki Hayabusa 12.5:1 Heavy Duty 84mm +3mm oversize bore x 63mm stroke (1396cc) piston kit

• Bore:  84mm
• Comp Ratio:  12.5:1
• Piston #:  M4004A
• CPK #:  CPK4004A
• Rod #:  4720
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPNG-2-3307
• Gasket Only #:  C8658

1999-2007 Suzuki Hayabusa 12.5:1 84mm +3mm oversize bore x 63mm stroke (1396cc) piston kit

• Bore:  84mm
• Comp Ratio:  12.5:1
• Piston #:  M4004B
• CPK #:  CPK4004B
• Rod #:  4720
• Pin #:  787-2000-12CP1C
• Locks #:  787x050 SWL
• Rings #:  CPNG-2-3307
• Gasket Only #:  C8658

1999-2007 Suzuki Hayabusa 14:0:1 gas ports 84mm +3mm oversize bore x 63mm stroke (1396cc) piston kit

• Bore:  84mm
• Comp Ratio:  14.0:1
• Piston #:  M4005B
• CPK #:  CPK4005
• Rod #:  4720
• Pin #:  787-2000-12CP1C
• Locks #:  787x050 SWL
• Rings #:  CPNG-2-3307
• Gasket Only #:  C8658

1999-2007 Suzuki Hayabusa 12.5:1 85mm +4mm oversize bore x 63mm stroke (1429cc) piston kit

• Bore:  85mm
• Comp Ratio:  12.5:1
• Piston #:  M4006B
• CPK #:  CPK4006
• Rod #:  4720
• Pin #:  787-2000-12CP1C
• Locks #:  787x050 SWL
• Rings #:  CPNG-2-3346
• Gasket Only #:  C8659

1999-2007 Suzuki Hayabusa 14.0:1 gas ports 85mm +4mm oversize bore x 63mm stroke (1429cc) piston kit

• Bore:  85mm
• Comp Ratio:  14.0:1
• Piston #:  M4007B
• CPK #:  CPK4007
• Rod #:  4720
• Pin #:  787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPNG-2-3346
• Gasket Only #:  C8659

1999-2007 Suzuki Hayabusa 9.5:1 Turbo 81mm std bore x 63mm stroke (1300cc) piston kit

• Bore:  81mm
• Comp Ratio:  9.5:1
• Piston #:  M4008
• CPK #:  CPK4008
• Rod #:  4720
• Pin #:  787-2250-16CP1C
• Locks #:  787x050 SWL
• Rings #:  CPNG-2-3189
• Gasket Only #:  C8656

1999-2007 Suzuki Hayabusa 12.5:1 81mm std bore x 63mm stroke (1300cc) piston kit

• Bore:  81mm
• Comp Ratio:  12.5:1
• Piston #:  M4034
• CPK #:  CPK4034
• Rod #:  4720
• Pin #:  787-2000-12CP1C
• Locks #:  787x050 SWL
• Rings #:  CPNG-2-3189
• Gasket Only #:  C8656

2004-2008 Honda CRF250R 14.5:1 78mm Std Bore x 52.2mm stroke platinum series 1mm Smaller Pin/ 2mm Longer Rod (249cc) piston kit

• Bore:  78mm
• Comp Ratio:  14.5:1
• Piston #:  MX2P08C
• CPK #:  CPKX2P08C
• Rod #:  8821
• Pin #:  S591-1650-13C
• Locks #:  591x040 SWL
• Rings #:  CP7800C
• Gasket Only #:  C7185-EST

2004-2008 Honda CRF250R 14.5:1 78mm std bore x 52.2mm stroke (249cc) piston kit

• Bore:  78mm
• Comp Ratio:  14.5:1
• Piston #:  MX2108C
• CPK #:  CPKX2108C
• Rod #:  8822
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7800C
• Gasket Only #:  C7185

2004-2008 Honda CRF250R 14.0:1 78mm std bore x 52.2mm stroke (249cc) piston kit

• Bore:  78mm
• Comp Ratio:  14.0:1
• Piston #:  MX2100C
• CPK #:  CPKX2100C
• Rod #:  8822
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7800C
• Gasket Only #:  C7185

2004-2008 Honda CRF250R 13.5:1 81mm +3mm oversize bore x 52.2mm stroke (268cc) piston kit

• Bore:  81mm
• Comp Ratio:  13.5:1
• Piston #:  MX2051C
• CPK #:  CPKX2051C
• Rod #:  8822
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP8100C
• Gasket Only #:  C7189

2004-2008 Honda CRF250R 13.5:1 78mm std bore x 52.2mm stroke (249cc) piston kit

• Bore:  78mm
• Comp Ratio:  13.5:1
• Piston #:  M2000C
• CPK #:  CPK2000C
• Rod #:  8822
• Pin #:  W630-1650-13CP1C
• Locks #:  630x050 SWL
• Rings #:  CP7800C
• Gasket Only #:  C7185

2004-2008 Honda CRF250R 13.0:1 78mm std bore x 52.2mm stroke (249cc) piston kit

• Bore:  78mm
• Comp Ratio:  13.0:1
• Piston #:  M2042C
• CPK #:  CPK2042C
• Rod #:  8822
• Pin #:  W630-1650-13CP1C
• Locks #:  630x050 SWL
• Rings #:  CP7800C
• Gasket Only #:  C7185

2004-2008 Honda CRF250R 13.5:1 78mm std bore x 52.2mm stroke (249cc) piston kit

• Bore:  78mm
• Comp Ratio:  13.5:1
• Piston #:  MX2000C
• CPK #:  CPKX2000C
• Rod #:  8822
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7800C
• Gasket Only #:  C7185

2002-2008 Honda CRF450R 13.5:1 96mm std bore x 62.1mm stroke platinum series1mm smaller pin/ 3mm longer rod (449cc) piston kit

• Bore:  96mm
• Comp Ratio:  13.5:1
• Piston #:  MX2P10
• CPK #:  CPKX2P10
• Rod #:  Call
• Pin #:  S708-2000-15C
• Locks #:  708x050 SWL
• Rings #:  CPN2-2-3779
• Gasket Only #:  C3047-EST

2002-2008 Honda CRF450R 12.5:1 96mm std bore x 62.1mm stroke (449cc) piston kit

• Bore:  96mm
• Comp Ratio:  12.5:1
• Piston #:  M2009
• CPK #:  CPK2009
• Rod #:  8820
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3779
• Gasket Only #:  C3047

2002-2008 Honda CRF450R 12.5:1 97mm +1mm oversize bore x 62.1mm stroke (459cc) piston kit

• Bore:  97mm
• Comp Ratio:  12.5:1
• Piston #:  M2011
• CPK #:  CPK2011
• Rod #:  8820
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3819
• Gasket Only #:  C3049

2002-2008 Honda CRF450R 13.5:1 97mm +1mm oversize bore x 62.1mm stroke (459cc) piston kit

• Bore:  97mm
• Comp Ratio:  13.5:1
• Piston #:  M2012
• CPK #:  CPK2012
• Rod #:  8820
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3819
• Gasket Only #:  C3049

2002-2008 Honda CRF450R 13.5:1 98mm +2mm oversize bore x 62.1mm stroke (468cc) piston kit

• Bore:  98mm
• Comp Ratio:  13.5:1
• Piston #:  M2014
• CPK #:  CPK2014
• Rod #:  8820
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPNZ-3858
• Gasket Only #:  C3049

2002-2008 Honda CRF450R 12.5:1 99mm +3mm oversize bore x 62.1mm stroke (478cc) piston Kit

• Bore:  99mm
• Comp Ratio:  12.5:1
• Piston #:  M2015
• CPK #:  CPK2015
• Rod #:  8820
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-3897
• Gasket Only #:  C3049

2002-2008 Honda CRF450R 13.0:1 96mm std bore x 62.1mm stroke (449cc) piston kit

• Bore:  96mm
• Comp Ratio:  13.0:1
• Piston #:  M2029
• CPK #:  CPK2029
• Rod #:  8820
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3779
• Gasket Only #:  C3047

2002-2008 Honda CRF450R 14.0:1 96mm std bore x 62.1mm stroke (449cc) piston kit

• Bore:  96mm
• Comp Ratio:  14.0:1
• Piston #:  MX2045
• CPK #:  CPKX2045
• Rod #:  8820
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3779
• Gasket Only #:  Call

2002-2008 Honda CRF450R 13.5:1 96mm std bore x 62.1mm stroke (449cc) piston kit

• Bore:  96mm
• Comp Ratio:  13.5:1
• Piston #:  MX2010
• CPK #:  CPKX2010
• Rod #:  8820
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3779
• Gasket Only #:  C3047

2002-2008 Honda CRF450R 12.5:1 96mm std bore x 62.1mm stroke (449cc) piston kit

• Bore:  96mm
• Comp Ratio:  12.5:1
• Piston #:  MX2009
• CPK #:  CPKX2009
• Rod #:  8820
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3779
• Gasket Only #:  C3047

2002-2008 Honda CRF450R 13.5:1 100mm +4mm oversize bore x 62.1mm stroke (488cc) piston kit

• Bore:  100mm
• Comp Ratio:  13.5:1
• Piston #:  M2052
• CPK #:  CPK2052
• Rod #:  8820
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3937
• Gasket Only #:  C3077

2003-2009 YZ450F 13.5:1 95mm std bore x 63.4mm stroke (449cc) piston kit

• Bore:  95mm
• Comp Ratio:  13.5:1
• Piston #:  M1011
• CPK #:  CPK1111
• Rod #:  9271
• Pin #:  W708-2000-15CP1C
• Locks #:  708x050 SWL
• Rings #:  CPN2-2-3740
• Gasket Only #:  2003-2004 C7947; 2006-2009 C7908

2003-2009 YZ450F 13.5:1 97mm +2mm oversize bore x 63.4mm stroke (468cc) piston kit

• Bore:  97mm
• Comp Ratio:  13.5:1
• Piston #:  M1031
• CPK #:  CPK1031
• Rod #:  9271
• Pin #:  708-2000-15CP1C
• Locks #:  708x050 SWL
• Rings #:  CPN2-3819
• Gasket Only #:  Call

2003-2009 YZ450F 13.5:1 98mm +3mm oversize bore x 63.4mm stroke (478cc) piston kit

• Bore:  98mm
• Comp Ratio:  13.5:1
• Piston #:  M1051
• CPK #:  CPK1051
• Rod #:  9271
• Pin #:  W708-2000-15CP1C
• Locks #:  708x050 SWL
• Rings #:  CPN2-3858
• Gasket Only #:  Call

2003--2009 YZ450F 13.5:1 95mm bore x 63.4mm stroke platinum series std. pin dia/ 2.5mm longer rod (449cc) piston kit

• Bore:  95mm
• Comp Ratio:  13.5:1
• Piston #:  MX1P43
• CPK #:  CPKX1P43
• Rod #:  6053
• Pin #:  S708-2000-15C
• Locks #:  708x050 SWL
• Rings #:  CPN2-2-3740
• Gasket Only #:  c

2003-2009 YZ450F 13.75:1 95mm std bore x 63.4mm stroke (449cc) piston kit

• Bore:  95mm
• Comp Ratio:  13.75:1
• Piston #:  MX1043
• CPK #:  CPKX1143
• Rod #:  9271
• Pin #:  S708-2000-15C
• Locks #:  708x050 SWL
• Rings #:  CPN2-2-3740
• Gasket Only #:  Call

2003-2009 YZ450F 13.0:1 95mm std bore 63.4mm stroke (449cc), piston kit

• Bore:  95mm
• Comp Ratio:  13.0:1
• Piston #:  M1010
• CPK #:  CPK1010
• Rod #:  9271
• Pin #:  W708-2000-15CP1C
• Locks #:  708x050 SWL
• Rings #:  CPN2-2-3740
• Gasket Only #:  2003-2004 C7947; 2006-2009 C7908

2003-2013 Suzuki LTZ 400 12.5:1 94mm +4mm oversize x 62.6mm stroke (434cc) piston kit

• Bore:  94mm
• Comp Ratio:  12.5:1
• Piston #:  M3003
• CPK #:  CPK3103
• Rod #:  5485
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3701
• Gasket Only #:  C7979

2003-2013 Suzuki LTZ 400 12.5:1 90mm std bore x 62.6mm stroke (398cc) piston kit

• Bore:  90mm
• Comp Ratio:  12.5:1
• Piston #:  M4028
• CPK #:  CPK4128
• Rod #:  5485
• Pin #:  787-1875-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3543
• Gasket Only #:  C7688

2003-2013 Suzuki LTZ 400 12.0:1 90mm std bore x 62.6mm stroke (398cc) piston kit

• Bore:  90mm
• Comp Ratio:  12.0:1
• Piston #:  M4023
• CPK #:  CPK4123
• Rod #:  5485
• Pin #:  787-1875-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3543
• Gasket Only #:  C7688

2003-2016 Suzuki DRZ 400 12.5:1 94mm +4mm oversize x 62.6mm stroke (434cc) piston kit

• Bore:  94mm
• Comp Ratio:  12.5:1
• Piston #:  M3003
• CPK #:  CPK3003
• Rod #:  5485
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3701
• Gasket Only #:  C7806

2003-2016 Suzuki DRZ 400 12.5:1 90mm std bore x 62.6mm stroke (398cc) piston kit

• Bore:  90mm
• Comp Ratio:  12.5:1
• Piston #:  M4028
• CPK #:  CPK4028
• Rod #:  5485
• Pin #:  787-1875-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3543
• Gasket Only #:  C7978

2003-2016 Suzuki DRZ 400 12.0:1 90mm std bore x 62.6mm stroke (398cc) piston kit

• Bore:  90mm
• Comp Ratio:  12.0:1
• Piston #:  M4023
• CPK #:  CPK4023
• Rod #:  5485
• Pin #:  787-1875-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-3543
• Gasket Only #:  C7978

2004-2007 KTM 450XC-G 12.5:1 95mm std bore x 63mm stock stroke (447.92cc) piston kit

• Bore:  95mm
• Comp Ratio:  12.5:1
• Piston #:  MX9004
• CPK #:  CPKX9004
• Rod #:  5418
• Pin #:  WPD787-2000-15C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3740
• Gasket Only #:  C7944

2004-2007 KTM 450XC-G 13.5:1 95mm std bore x 63mm stock stroke (447.92cc) piston kit

• Bore:  95mm
• Comp Ratio:  13.5:1
• Piston #:  M9005
• CPK #:  CPK9005
• Rod #:  5418
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3740
• Gasket Only #:  C7944

2004-2008 Honda CRF250R 14.5:1 78mm Std Bore x 52.2mm stroke platinum series 1mm Smaller Pin/ 2mm Longer Rod (249cc) piston kit

• Bore:  86mm
• Comp Ratio:  16.1:1
• Piston #:  M4135 * & ***
• CPK #:  Call
• Rod #:  7291
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN-3308
• Gasket Only #:  Call

2004-2008 Kawasaki KX 450F 13.0:1 96mm std bore x 62.1mm stroke (449cc) piston kit

• Bore:  96mm
• Comp Ratio:  13.0:1
• Piston #:  MX3009
• CPK #:  CPKX3009
• Rod #:  5402
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3779
• Gasket Only #:  C3136

2004-2008 Kawasaki KX 450F 13.0:1 96mm std bore x 62.1mm stroke (449cc) piston kit

• Bore:  96mm
• Comp Ratio:  13.0:1
• Piston #:  M3009
• CPK #:  CPK3009
• Rod #:  5402
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3779
• Gasket Only #:  C3136

2004-2008 Kawasaki KX 450F 13.5:1 96mm std bore x 62.1mm stroke, (449cc) piston kit

• Bore:  96mm
• Comp Ratio:  13.5:1
• Piston #:  MX3010
• CPK #:  CPKX3010
• Rod #:  5402
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3779
• Gasket Only #:  C3136

2016 Husqvarna FC 450 14.0:1 95mm std bore x 63.4mm stroke profiled pin bore (449.9cc) pro race piston kit

• Bore:  77mm
• Comp Ratio:  13.5:1
• Piston #:  MX3023C
• CPK #:  CPKX4117C
• Rod #:  8801
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7700C
• Gasket Only #:  C3054

2016 Husqvarna FC 450 13.5:1 95mm std bore x 63.4mm stroke profiled pin bore (449.9cc) pro race piston kit

• Bore:  77mm
• Comp Ratio:  13.5:1
• Piston #:  M3023C
• CPK #:  CPK4117C
• Rod #:  8801
• Pin #:  W630-1650-13CP1C
• Locks #:  630x050 SWL
• Rings #:  CP7700C
• Gasket Only #:  C3054

2005-2009 Kawasaki KX250F 14.2:1 77mm std bore x 53.6mm stroke (249cc) piston kit

• Bore:  77mm
• Comp Ratio:  14.2:1
• Piston #:  MX3000C
• CPK #:  CPKX4020C
• Rod #:  8801
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7700C
• Gasket Only #:  C3054

2005-2009 Kawasaki KX250F 13.5:1 79mm +2mm oversize bore x 53.6mm stroke (263cc) piston kit

• Bore:  79mm
• Comp Ratio:  13.5:1
• Piston #:  MX3002C
• CPK #:  CPKX3002C
• Rod #:  8801
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7900C
• Gasket Only #:  CALL

2005-2009 Kawasaki KX250F 12.5:1 81mm +4mm oversize bore x 53.6mm stroke (276cc) piston kit

• Bore:  81mm
• Comp Ratio:  12.5:1
• Piston #:  MX3007C
• CPK #:  CPKX3007C
• Rod #:  8801
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP8100C
• Gasket Only #:  CALL

2005-2009 Kawasaki KX250F 14.2:1 77mm std bore x 53.6mm stroke platinum series 1mm smaller pin 1.5 mm longer rod (249cc) piston kit

• Bore:  77mm
• Comp Ratio:  14.2:1
• Piston #:  MX3P00C
• CPK #:  CPKX3P00C
• Rod #:  8813
• Pin #:  S591-1650-13C
• Locks #:  591x040 SWL
• Rings #:  CP7700C
• Gasket Only #:  C3054

2005-2009 Kawasaki KX250F 13.5:1 80mm +3mm oversize bore x 53.6mm stroke (269cc) piston kit

• Bore:  80mm
• Comp Ratio:  13.5:1
• Piston #:  M3024C
• CPK #:  CPK3024C
• Rod #:  8801
• Pin #:  W630-1650-13CP1C
• Locks #:  630x050 SWL
• Rings #:  CP8000C
• Gasket Only #:  CALL
