2004-2007 KTM 450XC-G 13.5:1 95mm std bore x 63mm stock stroke (447.92cc) piston kit

• Bore:  95mm
• Comp Ratio:  13.5:1
• Piston #:  M9005
• CPK #:  CPK9005
• Rod #:  5418
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3740
• Gasket Only #:  C7944

2004-2007 KTM 450XC-G 12.5:1 95mm std bore x 63mm stock stroke (447.92cc) piston kit

• Bore:  95mm
• Comp Ratio:  12.5:1
• Piston #:  MX9004
• CPK #:  CPKX9004
• Rod #:  5418
• Pin #:  WPD787-2000-15C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3740
• Gasket Only #:  C7944

2005 KTM 450XC 12.0:1 89mm std bore x 72mm stroke (447.92cc), piston kit

• Bore:  89mm
• Comp Ratio:  12.0:1
• Piston #:  M9008
• CPK #:  CPK9008
• Rod #:  5418
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3504
• Gasket Only #:  C3263

2005 KTM 450XC 13.0:1 89mm std bore x 72mm stroke (447.92cc), piston kit

• Bore:  89mm
• Comp Ratio:  13.0:1
• Piston #:  M9009
• CPK #:  CPK9009
• Rod #:  5418
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3504
• Gasket Only #:  C3263

2006-2010 KTM 250 SX-F 13.5:1 79mm+3mm oversize bore x 54.8mm stroke (270cc) piston kit

• Bore:  79mm
• Comp Ratio:  13.5:1
• Piston #:  MX9031C
• CPK #:  CPKX9031C
• Rod #:  5415
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7900C
• Gasket Only #:  C3184

2006-2010 KTM 250 SX-F 13.5:1 76mm std bore x 54.8mm stroke (248.6cc) piston kit

• Bore:  76mm
• Comp Ratio:  13.5:1
• Piston #:  M9003C
• CPK #:  CPK9003C
• Rod #:  5415
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7600C
• Gasket Only #:  C3164-HB

2006-2010 KTM 250 SX-F 13.5:1 76mm std bore x 54.8mm stroke (249cc) piston kit

• Bore:  76mm
• Comp Ratio:  13.5:1
• Piston #:  MX9003C
• CPK #:  CPKX9003C
• Rod #:  5415
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7600C
• Gasket Only #:  C3164-HB

2007-2012 KTM 450 SX-F 13.5:1 97mm std bore x 60.8mm stroke (449.30cc) iston kit

• Bore:  97mm
• Comp Ratio:  13.5:1
• Piston #:  MX9007
• CPK #:  CPKX9007
• Rod #:  8814
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3819
• Gasket Only #:  C3412

2007-2012 KTM 450SX-F 13.0:1 97mm std bore x 60.8mm stroke (449.30cc) piston kit

• Bore:  97mm
• Comp Ratio:  13.0:1
• Piston #:  MX9006
• CPK #:  CPKX9006
• Rod #:  8814
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3819
• Gasket Only #:  C3412

2007-2012 KTM 450 SX-F 13.5:1 97mm std bore x 60.8mm stroke (449.30cc) piston kit

• Bore:  97mm
• Comp Ratio:  13.5:1
• Piston #:  M9007
• CPK #:  CPK9007
• Rod #:  8814
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3819
• Gasket Only #:  C3412

2007-2012 KTM 450SX-F 13.0:1 97mm std bore x 60.8mm stroke (449.30cc) piston kit

• Bore:  97mm
• Comp Ratio:  13.0:1
• Piston #:  M9006
• CPK #:  CPK9006
• Rod #:  8814
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3819
• Gasket Only #:  C3412

2007-2012 KTM 505 SX/XC 13.5:1 100mm std bore x 60.8mm stroke (477.5cc) piston kit

• Bore:  100mm
• Comp Ratio:  13.5:1
• Piston #:  MX9022
• CPK #:  CPKX9022
• Rod #:  N/A
• Pin #:  S787-2000-15C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3937
• Gasket Only #:  C3413

2007-2012 KTM 505 SX/XC 13.0:1 100mm std bore x 60.8mm stroke (47.57cc) piston kit

• Bore:  100mm
• Comp Ratio:  13.0:1
• Piston #:  MX9030
• CPK #:  CPKX9030
• Rod #:  N/A
• Pin #:  WPD787-2000-15C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3937
• Gasket Only #:  C3413

2007-2012 KTM 505 SX/XC 13.5:1 100mm std bore x 60.8mm stroke (477.5cc) piston kit

• Bore:  100mm
• Comp Ratio:  13.5:1
• Piston #:  MX9022
• CPK #:  CPKX9022
• Rod #:  N/A
• Pin #:  S787-2000-15C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3937
• Gasket Only #:  C3413

2007-2012 KTM 505 SX/XC 13.0:1 100mm std bore x 60.8mm stroke (47.57cc) piston kit

• Bore:  100mm
• Comp Ratio:  13.0:1
• Piston #:  MX9030
• CPK #:  CPKX9030
• Rod #:  N/A
• Pin #:  WPD787-2000-15C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3937
• Gasket Only #:  C3413

2008-2012 KTM 450XC 13.5:1 89mm std bore x 72mm stroke (447.92cc) piston kit

• Bore:  89mm
• Comp Ratio:  13.5:1
• Piston #:  M9010
• CPK #:  CPK9010
• Rod #:  5418
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3504
• Gasket Only #:  C3263

2008-2012 KTM 525XC 13.0:1 95mm std bore x 72mm stroke (510.4cc) piston kit

• Bore:  95mm
• Comp Ratio:  13.0:1
• Piston #:  M9012
• CPK #:  CPK9012
• Rod #:  5418
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3740
• Gasket Only #:  C7944

2008-2012 KTM 525XC 12.0:1 95mm std bore x 72mm stroke (510.4cc) piston kit

• Bore:  95mm
• Comp Ratio:  12.0:1
• Piston #:  M9011
• CPK #:  CPK9011
• Rod #:  5418
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3740
• Gasket Only #:  C7944

2011-2012 KTM 250 SX-F 14.0:1 76mm std bore x 54.8mm stroke (249cc) piston kit

• Bore:  76mm
• Comp Ratio:  14.0:1
• Piston #:  MX9034C
• CPK #:  CPKX9034C
• Rod #:  5415
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7600C
• Gasket Only #:  C3164-HB

2013-2015 KTM 250SX-F 14.7:1 78mm std bore x 52.3mm stroke (249.91cc) piston kit

• Bore:  78mm
• Comp Ratio:  14.7:1
• Piston #:  MX9046C
• CPK #:  CPKX9046C
• Rod #:  N/A
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7800C
• Gasket Only #:  C3511

2013-15 KTM SX-F 13.0:1 95mm std bore x 63.4mm stroke (449.3cc) piston kit

• Bore:  95mm
• Comp Ratio:  13.0:1
• Piston #:  MX9045
• CPK #:  CPKX9045
• Rod #:  N/A
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3740
• Gasket Only #:  C3241

2016 KTM 450 SX-F 13.5:1 95mm std bore x 63.4mm stroke profiled pin bore (449.9cc) pro race piston kit

• Bore:  95mm
• Comp Ratio:  13.5:1
• Piston #:  MX9061-P
• CPK #:  Call
• Rod #:  N/A
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CP9500C
• Gasket Only #:  Call

2016 KTM 450 SX-F 14.0:1 95mm std bore x 63.4mm stroke profiled pin bore (449.9cc) pro race piston kit

• Bore:  95mm
• Comp Ratio:  14.0:1
• Piston #:  MX9062-P
• CPK #:  Call
• Rod #:  N/A
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CP9500C
• Gasket Only #:  Call

2016-2019 KTM 250SX-F 14.7:1 78mm std bore x 52.3mm stroke profiled pin bore (249.9cc) pro race piston kit

• Bore:  78mm
• Comp Ratio:  14.7:1
• Piston #:  MX9060-P
• CPK #:  CPKX9060-P
• Rod #:  N/A
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7800C
• Gasket Only #:  C3595
