2007-2012 KTM 450 SX-F 13.5:1 97mm std bore x 60.8mm stroke (449.30cc) piston kit

• Bore:  97mm
• Comp Ratio:  13.5:1
• Piston #:  M9007
• CPK #:  CPK9007
• Rod #:  8814
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3819
• Gasket Only #:  C3412

2007-2012 KTM 450SX-F 13.0:1 97mm std bore x 60.8mm stroke (449.30cc) piston kit

• Bore:  97mm
• Comp Ratio:  13.0:1
• Piston #:  MX9006
• CPK #:  CPKX9006
• Rod #:  8814
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3819
• Gasket Only #:  C3412

2007-2012 KTM 450 SX-F 13.5:1 97mm std bore x 60.8mm stroke (449.30cc) iston kit

• Bore:  97mm
• Comp Ratio:  13.5:1
• Piston #:  MX9007
• CPK #:  CPKX9007
• Rod #:  8814
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3819
• Gasket Only #:  C3412

2007-2012 KTM 505 SX/XC 13.5:1 100mm std bore x 60.8mm stroke (477.5cc) piston kit

• Bore:  100mm
• Comp Ratio:  13.5:1
• Piston #:  MX9022
• CPK #:  CPKX9022
• Rod #:  N/A
• Pin #:  S787-2000-15C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3937
• Gasket Only #:  C3413

2007-2012 KTM 505 SX/XC 13.0:1 100mm std bore x 60.8mm stroke (47.57cc) piston kit

• Bore:  100mm
• Comp Ratio:  13.0:1
• Piston #:  MX9030
• CPK #:  CPKX9030
• Rod #:  N/A
• Pin #:  WPD787-2000-15C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3937
• Gasket Only #:  C3413

2007-2012 KTM 505 SX/XC 13.5:1 100mm std bore x 60.8mm stroke (477.5cc) piston kit

• Bore:  100mm
• Comp Ratio:  13.5:1
• Piston #:  MX9022
• CPK #:  CPKX9022
• Rod #:  N/A
• Pin #:  S787-2000-15C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3937
• Gasket Only #:  C3413

2007-2012 KTM 505 SX/XC 13.0:1 100mm std bore x 60.8mm stroke (47.57cc) piston kit

• Bore:  100mm
• Comp Ratio:  13.0:1
• Piston #:  MX9030
• CPK #:  CPKX9030
• Rod #:  N/A
• Pin #:  WPD787-2000-15C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3937
• Gasket Only #:  C3413

2002-2008 Honda CRF450R 13.0:1 96mm std bore x 62.1mm stroke (449cc) piston kit

• Bore:  96mm
• Comp Ratio:  13.0:1
• Piston #:  MX2029
• CPK #:  CPKX2029
• Rod #:  8820
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3779
• Gasket Only #:  C3047

2006-2014 Yamaha Raptor/Rhino 700 12.0:1 102mm std bore x 84mm stroke (686cc) piston kit

• Bore:  102mm
• Comp Ratio:  12.0:1
• Piston #:  M1040A
• CPK #:  CPK1040A
• Rod #:  5023
• Pin #:  W905-2250-15CP1C
• Locks #:  905X073 SWL
• Rings #:  CPN-4016
• Gasket Only #:  C3142
