2005-2015 RXP 215/255/260 8.4:1 turbo 100.25mm +.25mm oversize bore x 63.4mm stroke (1501cc) piston kit

• Bore:  100.25mm
• Comp Ratio:  8.4:1
• Piston #:  M9033
• CPK #:  CPK9033
• Rod #:  5476
• Pin #:  905-2250-19CP3C
• Locks #:  905X073 SWL
• Rings #:  SWF-20064-3
• Gasket Only #:  H30220305

2005-2015 RXP 215/255/260 9.5:1 turbo 100mm std bore x 63.4mm stroke (1494cc) piston kit

• Bore:  100mm
• Comp Ratio:  9.5:1
• Piston #:  M9039A
• CPK #:  CPK9039A
• Rod #:  5476
• Pin #:  905-2250-19CP3C
• Locks #:  905X073 SWL
• Rings #:  CPN-3937
• Gasket Only #:  H30220305

2005-2015 RXP 215/255/260 9.5:1 turbo 100.25mm +.25mm oversize bore x 63.4mm stroke (1501cc) piston kit

• Bore:  100.25mm
• Comp Ratio:  9.5:1
• Piston #:  M9040
• CPK #:  CPK9040
• Rod #:  5476
• Pin #:  905-2250-19CP3C
• Locks #:  905X073 SWL
• Rings #:  SWF-20064-3
• Gasket Only #:  H30220305

2005-2015 RXP 215/255/260 8.2:1 turbo 100.5mm +.5mm oversize bore x 63.4mm stroke (1508cc) piston kit

• Bore:  100.5mm
• Comp Ratio:  8.2:1
• Piston #:  M9041
• CPK #:  CPK9041
• Rod #:  5476
• Pin #:  905-2250-19CP3C
• Locks #:  905X073 SWL
• Rings #:  CPN-3957
• Gasket Only #:  H30220305

2005-2015 RXP 215/255/260 9.5:1 turbo, 100.5mm +.5mm oversize bore x 63.4mm stroke (1508cc) piston kit

• Bore:  100.5mm
• Comp Ratio:  9.5:1
• Piston #:  M9042
• CPK #:  CPK9042
• Rod #:  5476
• Pin #:  905-2250-19CP3C
• Locks #:  905X073 SWL
• Rings #:  CPN-3957
• Gasket Only #:  H30220305

2006-2010 KTM 250 SX-F 13.5:1 76mm std bore x 54.8mm stroke (248.6cc) piston kit

• Bore:  76mm
• Comp Ratio:  13.5:1
• Piston #:  M9003C
• CPK #:  CPK9003C
• Rod #:  5415
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7600C
• Gasket Only #:  C3164-HB

2006-2010 KTM 250 SX-F 13.5:1 76mm std bore x 54.8mm stroke (249cc) piston kit

• Bore:  76mm
• Comp Ratio:  13.5:1
• Piston #:  MX9003C
• CPK #:  CPKX9003C
• Rod #:  5415
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7600C
• Gasket Only #:  C3164-HB

2006-2010 KTM 250 SX-F 13.5:1 79mm+3mm oversize bore x 54.8mm stroke (270cc) piston kit

• Bore:  79mm
• Comp Ratio:  13.5:1
• Piston #:  MX9031C
• CPK #:  CPKX9031C
• Rod #:  5415
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7900C
• Gasket Only #:  C3184

2006-2011 Kawasaki ZX14 9.5:1 Turbo 84mm std bore x 61mm stroke (1352cc) piston kit

• Bore:  84mm
• Comp Ratio:  9.5:1
• Piston #:  M4035
• CPK #:  Call
• Rod #:  5412
• Pin #:  787-2250-16CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN-3307
• Gasket Only #:  Call

2006-2011 Kawasaki ZX14 13.5:1 84mm std bore x 61mm stroke (1352cc) piston kit

• Bore:  84mm
• Comp Ratio:  13.5:1
• Piston #:  M4036
• CPK #:  Call
• Rod #:  5412
• Pin #:  787-2000-12CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN-3307
• Gasket Only #:  Call

2006-2011 Kawasaki ZX14 13.25:1 86mm +2mm oversize bore x 61mm stroke (1418cc) piston kit

• Bore:  86mm
• Comp Ratio:  13.25:1
• Piston #:  M4037
• CPK #:  Call
• Rod #:  5412
• Pin #:  787-2000-12CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN-3307
• Gasket Only #:  Call

2006-2011 Kawasaki ZX14 14.0:1 87mm +3mm oversize bore x 61mm stroke (1450cc) piston kit

• Bore:  87mm
• Comp Ratio:  14.0:1
• Piston #:  M4038
• CPK #:  Call
• Rod #:  5412
• Pin #:  787-2000-12CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN-3425
• Gasket Only #:  Call

2006-2011 Kawasaki ZX14 13.25:1 86mm +2mm oversize bore x 61mm stroke (1418cc) piston kit

• Bore:  86mm
• Comp Ratio:  15.4:1
• Piston #:  M4136
• CPK #:  Call
• Rod #:  5412
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN-3308
• Gasket Only #:  Call

2006-2011 Kawasaki ZX14 14.0:1 87mm +3mm oversize bore x 61mm stroke (1450cc) piston kit

• Bore:  87mm
• Comp Ratio:  15.7:1
• Piston #:  M4137
• CPK #:  Call
• Rod #:  5412
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPNG-2-3425
• Gasket Only #:  Call

2006-2011 Kawasaki ZX14 13.25:1 86mm +2mm oversize bore x 66mm stroke (1418cc) nitrous 150 shot piston kit

• Bore:  86mm
• Comp Ratio:  15.5:1
• Piston #:  M4135 ***
• CPK #:  Call
• Rod #:  5412
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN-3308
• Gasket Only #:  Call

2006-2011 Suzuki LTR450 13.0:1 95.5mm std bore x 62.8mm stroke (449cc) piston kit

• Bore:  95.5mm
• Comp Ratio:  13.0:1
• Piston #:  M4010A
• CPK #:  CPK4010A
• Rod #:  8811
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3759
• Gasket Only #:  C3208

2006-2011 Suzuki LTR450 12.5:1 98mm +2.5mm oversize bore x 62.8mmm stroke (473cc) piston kit

• Bore:  98mm
• Comp Ratio:  12.5:1
• Piston #:  M4012
• CPK #:  CPK4012
• Rod #:  8811
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-3858
• Gasket Only #:  C3157

2006-2011 Suzuki LTR450 11.7:1 95.5mm std bore x 62.8mm stroke (449cc) piston kit

• Bore:  95.5mm
• Comp Ratio:  11.7:1
• Piston #:  M4024
• CPK #:  CPK4024
• Rod #:  8811
• Pin #:  748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3759
• Gasket Only #:  C3208

2006-2011 Suzuki LTR450 13.0:1 95.5mm std bore x 62.8mm stroke (449cc) piston kit

• Bore:  95.5mm
• Comp Ratio:  13.0:1
• Piston #:  M4110A
• CPK #:  CPK4110A
• Rod #:  8811
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-3759
• Gasket Only #:  C3208

2006-2011 Suzuki LTR450 13.0:1 95.5mm std bore x 62.8mm stroke (449cc) piston kit

• Bore:  95.5mm
• Comp Ratio:  13.0:1
• Piston #:  MX4010A
• CPK #:  CPKX4010A
• Rod #:  8811
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3759
• Gasket Only #:  C3208

2006-2011 Suzuki LTR 450 13.5:1 95.5mm std bore x 62.8mm stroke (449cc) piston kit

• Bore:  95.5mm
• Comp Ratio:  13.5:1
• Piston #:  MX4011A
• CPK #:  CPKX4011A
• Rod #:  8811
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3759
• Gasket Only #:  C3208

2006-2011 Suzuki LTR450 13.75:1 95.5mm std bore x 62.8mm stroke (449cc) piston kit

• Bore:  95.5mm
• Comp Ratio:  13.75:1
• Piston #:  MX4015A
• CPK #:  CPKX4015A
• Rod #:  8811
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3759
• Gasket Only #:  C3208

20062011 Suzuki LTR450 13.75:1 95.5mm std bore x 62.8mm stroke platinum series std pin diameter/ 3mm longer rod (449cc) piston kit

• Bore:  95.5mm
• Comp Ratio:  13.75:1
• Piston #:  MX4P15A
• CPK #:  CPKX4P15A
• Rod #:  6124
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3759
• Gasket Only #:  C3208

2006-2014 Yamaha Raptor/Rhino 700 11.0:1 102mm std bore x 84mm stroke (686cc) piston kit

• Bore:  102mm
• Comp Ratio:  11.0:1
• Piston #:  M1039A
• CPK #:  CPK1039A
• Rod #:  5023
• Pin #:  W905-2250-15CP1C
• Locks #:  905X073 SWL
• Rings #:  CPN-4016
• Gasket Only #:  C3142

2006-2014 Yamaha RaptorRhino 700 10.75 105mm +3mm oversize bore x 84mm stroke (727cc) piston kit

• Bore:  105mm
• Comp Ratio:  10.75:1
• Piston #:  M1041A
• CPK #:  CPK1041A
• Rod #:  5023
• Pin #:  W905-2250-15CP1C
• Locks #:  905X073 SWL
• Rings #:  CPN-4134
• Gasket Only #:  C3144

2006-2014 Yamaha Raptor/Rhino 700 12:1 105mm +3mm oversize bore x 84mm stroke (727cc) piston kit

• Bore:  105mm
• Comp Ratio:  12.0:1
• Piston #:  M1042A
• CPK #:  CPK1042A
• Rod #:  5023
• Pin #:  W905-2250-15CP1C
• Locks #:  905X073 SWL
• Rings #:  CPN-4134
• Gasket Only #:  C3144

2006-2014 Yamaha Raptor/Rhino 700 10.0:1 102mm std bore x 84mm stroke (686cc) piston kit

• Bore:  102mm
• Comp Ratio:  10.0:1
• Piston #:  M1045
• CPK #:  CPK1045
• Rod #:  5023
• Pin #:  905-2250-15CP1C
• Locks #:  905X073 SWL
• Rings #:  CPN-4016
• Gasket Only #:  C3142

2006-2014 Yamaha Raptor/Rhino 700 13:1 105mm +3mm oversize bore x 84mm stroke (727cc) piston kit

• Bore:  105mm
• Comp Ratio:  13.0:1
• Piston #:  M1053A
• CPK #:  CPK1053A
• Rod #:  5023
• Pin #:  W905-2250-15CP1C
• Locks #:  905X073 SWL
• Rings #:  CPN-4134
• Gasket Only #:  C3144

2006-2014 Yamaha Raptor/Rhino 700 12.5:1 105.5mm +3mm oversize bore x 84mm stroke (734cc) piston kit

• Bore:  105.5mm
• Comp Ratio:  12.5:1
• Piston #:  M1054
• CPK #:  CPK1054
• Rod #:  5023
• Pin #:  W905-2250-15CP1C
• Locks #:  905X073 SWL
• Rings #:  RS1000NCR-4150-5
• Gasket Only #:  C3144

2006-2014 Yamaha Raptor/Rhino 700 10.75:1 105.5mm +3mm oversize bore x 84mm stroke (734cc) piston kit

• Bore:  105.5mm
• Comp Ratio:  10.75:1
• Piston #:  M1086
• CPK #:  CPK1086
• Rod #:  5023
• Pin #:  W905-2250-15CP1C
• Locks #:  905X073 SWL
• Rings #:  RS1000NCR-4150-5
• Gasket Only #:  C3144

2006-2014 Yamaha Raptor/Rhino 700 11.0:1 102mm std bore x 84mm stroke (686cc) piston kit

• Bore:  102mm
• Comp Ratio:  11.0:1
• Piston #:  M1039A
• CPK #:  CPK1039A
• Rod #:  5023
• Pin #:  W905-2250-15CP1C
• Locks #:  905X073 SWL
• Rings #:  CPN-4016
• Gasket Only #:  C3142

2006-2014 Yamaha Raptor/Rhino 700 12.0:1 102mm std bore x 84mm stroke (686cc) piston kit

• Bore:  102mm
• Comp Ratio:  12.0:1
• Piston #:  M1040A
• CPK #:  CPK1040A
• Rod #:  5023
• Pin #:  W905-2250-15CP1C
• Locks #:  905X073 SWL
• Rings #:  CPN-4016
• Gasket Only #:  C3142

2006-2014 Yamaha RaptorRhino 700 10.75 105mm +3mm oversize bore x 84mm stroke (727cc) piston kit

• Bore:  105mm
• Comp Ratio:  10.75:1
• Piston #:  M1041A
• CPK #:  CPK1041A
• Rod #:  5023
• Pin #:  W905-2250-15CP1C
• Locks #:  905X073 SWL
• Rings #:  CPN-4134
• Gasket Only #:  C3144

2006-2014 Yamaha Raptor/Rhino 700 12:1 105mm +3mm oversize bore x 84mm stroke (727cc) piston kit

• Bore:  105mm
• Comp Ratio:  12.0:1
• Piston #:  M1042A
• CPK #:  CPK1042A
• Rod #:  5023
• Pin #:  W905-2250-15CP1C
• Locks #:  905X073 SWL
• Rings #:  CPN-4134
• Gasket Only #:  C3144

2006-2014 Yamaha Raptor/Rhino 700 10.0:1 102mm std bore x 84mm stroke (686cc) piston kit

• Bore:  102mm
• Comp Ratio:  10.0:1
• Piston #:  M1045
• CPK #:  CPK1045
• Rod #:  5023
• Pin #:  905-2250-15CP1C
• Locks #:  905X073 SWL
• Rings #:  CPN-4016
• Gasket Only #:  C3142

2006-2014 Yamaha Raptor/Rhino 700 13:1 105mm +3mm oversize bore x 84mm stroke (727cc) piston kit

• Bore:  105mm
• Comp Ratio:  13.0:1
• Piston #:  M1053A
• CPK #:  CPK1053A
• Rod #:  5023
• Pin #:  W905-2250-15CP1C
• Locks #:  905X073 SWL
• Rings #:  CPN-4134
• Gasket Only #:  C3144

2006-2014 Yamaha Raptor/Rhino 700 12.5:1 105.5mm +3mm oversize bore x 84mm stroke (734cc) piston kit

• Bore:  105.5mm
• Comp Ratio:  12.5:1
• Piston #:  M1054
• CPK #:  CPK1054
• Rod #:  5023
• Pin #:  W905-2250-15CP1C
• Locks #:  905X073 SWL
• Rings #:  RS1000NCR-4150-5
• Gasket Only #:  C3144

2006-2014 Yamaha Raptor/Rhino 700 10.75:1 105.5mm +3mm oversize bore x 84mm stroke (734cc) piston kit

• Bore:  105.5mm
• Comp Ratio:  10.75:1
• Piston #:  M1086
• CPK #:  CPK1086
• Rod #:  5023
• Pin #:  W905-2250-15CP1C
• Locks #:  905X073 SWL
• Rings #:  RS1000NCR-4150-5
• Gasket Only #:  C3144

2006 - 2015 Honda TRX450R 12.5:1 96mm std bore x 62mm stroke (449cc) piston kit

• Bore:  96mm
• Comp Ratio:  12.5:1
• Piston #:  M2036
• CPK #:  CPK2036
• Rod #:  8804
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-3780
• Gasket Only #:  C3139

2006-2015 Honda TRX450R 13.0:1 96mm std bore x 62mm stroke (449cc) piston kit

• Bore:  96mm
• Comp Ratio:  13.0:1
• Piston #:  M2037
• CPK #:  CPK2037
• Rod #:  8804
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-3780
• Gasket Only #:  C3139

2006-2015 Honda TRX450R 12.5:1 98mm +2mm oversize bore x 62mm stroke (468cc) piston kit

• Bore:  98mm
• Comp Ratio:  12.5:1
• Piston #:  M2038
• CPK #:  CPK2038
• Rod #:  8804
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-3858
• Gasket Only #:  C3141

2006-2015 Honda TRX450R 13.5:1 96mm std bore x 62mm stroke (449cc) piston kit

• Bore:  96mm
• Comp Ratio:  13.5:1
• Piston #:  M2053
• CPK #:  CPK2053
• Rod #:  8804
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-3780
• Gasket Only #:  C3139

2006-2015 Honda TRX450R 13.0:1 100mm +4mm oversize bore x 62mm stroke (486cc) piston kit

• Bore:  100mm
• Comp Ratio:  13.0:1
• Piston #:  M2054
• CPK #:  CPK2054
• Rod #:  8804
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-3937
• Gasket Only #:  C3156

2006 - 2015 Honda TRX450R 12.0:1 96mm std bore x 62mm stroke (449cc) piston kit

• Bore:  96mm
• Comp Ratio:  12.0:1
• Piston #:  M2136
• CPK #:  CPK2136
• Rod #:  8804
• Pin #:  748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-3780
• Gasket Only #:  C3139

2006-2015 Honda TRX450R 14.0:1 96mm std bore x 62mm stroke (449cc) piston kit

• Bore:  96mm
• Comp Ratio:  14.0:1
• Piston #:  MX2045
• CPK #:  CPKX2145
• Rod #:  8804
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3779
• Gasket Only #:  C3139

2006-2015 Honda TRX450R 14.0:1 96mm std bore x 62mm stroke platinum series pin dia/ 2.5mm longer rod (449cc) piston kit

• Bore:  96mm
• Comp Ratio:  14.0:1
• Piston #:  MX2P45
• CPK #:  CPKX2145-P
• Rod #:  9078
• Pin #:  S748-2000-15C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3779
• Gasket Only #:  C3139-EST

2006-2017 Yamaha R6 13.1:1, 67mm std bore x 42.5mm stroke (600cc) piston kit

• Bore:  67mm
• Comp Ratio:  13.1:1
• Piston #:  M1075
• CPK #:  Call
• Rod #:  Light 7466; HD 9584
• Pin #:  591-1500-13CP1C
• Locks #:  591x050 SWL
• Rings #:  MAC06700
• Gasket Only #:  CALL

2006-2017 Yamaha R6 13.5:1, 69mm +2mm oversize bore x 42.5mm stroke (635cc) piston kit

• Bore:  69mm
• Comp Ratio:  13.6:1
• Piston #:  M1076-050
• CPK #:  Call
• Rod #:  Light 7466; HD 9584
• Pin #:  591-1500-11CP1C
• Locks #:  591x050 SWL
• Rings #:  MAC06900
• Gasket Only #:  CALL

2007-2008 Yamaha R1 13:1 , 77mm std bore x 53.6mm stroke (998cc) piston kit

• Bore:  77mm
• Comp Ratio:  13.0:1
• Piston #:  M1055C
• CPK #:  CPK1055C
• Rod #:  5021
• Pin #:  669-1650-12CP1C
• Locks #:  669X050 SWL
• Rings #:  Rings CPXG7700C (CP7700C top and oil, XG3031 second)
• Gasket Only #:  C8767

2007-2008 Yamaha R 13:1 79mm +2mm oversize bore x 53.6mm stroke (998cc) piston kit

• Bore:  79mm
• Comp Ratio:  13.0:1
• Piston #:  M1056C
• CPK #:  CPK1056C
• Rod #:  5021
• Pin #:  669-1650-12CP1C
• Locks #:  669x050 SWL
• Rings #:  CPXG7900C (CP7900C top and oil, XG3110 second)
• Gasket Only #:  C8767

2007-2009 Suzuki RM-Z250 14.2:1 77mm std bore x 53.6mm stroke (249cc) piston kit

• Bore:  77mm
• Comp Ratio:  14.2:1
• Piston #:  M3016C
• CPK #:  CPK3016C
• Rod #:  8801
• Pin #:  W630-1650-13CP1C
• Locks #:  630x050 SWL
• Rings #:  CP7700C
• Gasket Only #:  C3175

2007-2009 Suzuki RM-Z250 13.5:1 77mm std bore x 53.6mm stroke (249cc) piston kit

• Bore:  77mm
• Comp Ratio:  13.5:1
• Piston #:  M3017C
• CPK #:  CPK3017C
• Rod #:  8801
• Pin #:  W630-1650-13CP1C
• Locks #:  630x050 SWL
• Rings #:  CP7700C
• Gasket Only #:  C3175

2007-2009 Suzuki RM-Z250 13.5:1 79mm +2mm oversize bore x 53.6mm stroke (263cc) piston kit

• Bore:  79mm
• Comp Ratio:  13.5:1
• Piston #:  MX3002C
• CPK #:  CPKX3102C
• Rod #:  8801
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7900C
• Gasket Only #:  C3177

2007-2009 Suzuki RM-Z250 14.2:1 77mm std bore x 53.6mm stroke (249cc) piston kit

• Bore:  77mm
• Comp Ratio:  14.2:1
• Piston #:  MX3016C
• CPK #:  CPKX3016C
• Rod #:  8801
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7700C
• Gasket Only #:  C3175

2007-2009 Suzuki RM-Z250 13.5:1 77mm std bore x 53.6mm stroke (249cc) piston kit

• Bore:  77mm
• Comp Ratio:  13.5:1
• Piston #:  MX3017C
• CPK #:  CPKX3017C
• Rod #:  8801
• Pin #:  S630-1650-13C
• Locks #:  630x050 SWL
• Rings #:  CP7700C
• Gasket Only #:  C3175

2007-2011 Polaris Outlaw 12.0:1 95mm std bore x 72mm stroke (525cc) piston kit

• Bore:  95mm
• Comp Ratio:  12.0:1
• Piston #:  M9011
• CPK #:  CPK9047
• Rod #:  5418
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3740
• Gasket Only #:  C7944

2007-2011 Polaris Outlaw 13.0:1 95mm std bore x 72mm stroke (525cc) piston kit

• Bore:  95mm
• Comp Ratio:  13.1:1
• Piston #:  M9012
• CPK #:  CPK9048
• Rod #:  5418
• Pin #:  W787-2000-15CP1C
• Locks #:  787x050 SWL
• Rings #:  CPN2-2-3740
• Gasket Only #:  C7944

2007-2017 Honda CRF150R 13.0:1 66mm std bore x 43.7mm stroke (149cc) piston kit use with stock style valves

• Bore:  66mm
• Comp Ratio:  13.0:1
• Piston #:  M2043C
• CPK #:  CPK2043C
• Rod #:  8750
• Pin #:  W551-1500-12CP1C
• Locks #:  551x040 SWL
• Rings #:  CP6600C
• Gasket Only #:  C3187

2007-2017 Honda CRF150R 13.0:1 66mm bore x 43.7mm stroke (149cc) piston kit use with flat vlaves

• Bore:  66mm
• Comp Ratio:  13.0:1
• Piston #:  M2044C
• CPK #:  CPK2044C
• Rod #:  8750
• Pin #:  W551-1500-12CP1C
• Locks #:  551x040 SWL
• Rings #:  CP6600C
• Gasket Only #:  C3187

2007-2012 KTM 450SX-F 13.0:1 97mm std bore x 60.8mm stroke (449.30cc) piston kit

• Bore:  97mm
• Comp Ratio:  13.0:1
• Piston #:  M9006
• CPK #:  CPK9006
• Rod #:  8814
• Pin #:  W748-2000-15CP1C
• Locks #:  748x050 SWL
• Rings #:  CPN2-2-3819
• Gasket Only #:  C3412
